| Attribute | Value |
|---|---|
| Dimension | L870mm X W1230mm X H1550mm |
| Max carrier size | Max:350(L)*300(W)(mm) |
| Temperature setting range | Max400 ℃ |
| Position accuracy | + / - 0.05 mm |
| Solder pot capacity | 13 kgs /PCS |
| Preheat method | Upper IR heating |
| Machine Parameters | |
|---|---|
| Dimensions | L870mm X W1230mm X H1550mm |
| Power supply | Single phase 220V 50HZ |
| Shipping Parameters | |
|---|---|
| Rail adjustable range | 50-300MM |
| PCB board size | L350 X W300MM |
| Transport height | 900±30mm |
| Sports platform | Pulley + slide rail |
| Movement accuracy | ±0.25 mm |
| Tin Furnace Parameters | |
|---|---|
| Crest drive | Mechanical pump |
| Number of tin furnaces | Single cylinder |
| Tin furnace capacity | 13 kg / furnace |
| Nitrogen consumption | About 1.5 ~2 m3/h per tin cylinder |
| Programmatically | Manually enter coordinates |
